Zotac IONITX-F series User Manual

6
NVIDIA ION PCIEx16 series Motherboard
Motherboard Layout
Figure 1 shows the motherboard and Figure 2 shows the back panel connectors.
Figure 1. Board Layout
20-pin ATX Power Connector
System Fan Connector
Front Panel Header
Speaker Header
SPDIF-out Header
COM Header
Serial-ATA (SATA) Connectors
PCI Express x16
Clear CMOS Jumper
Mini PCIE Slot
