Zotac MAG

Setting up your ZOTAC MAG
Connect the peripherals before using your ZOTAC MAG.
Connecting to USB devices
Connect USB devices such as keyboards (varying with areas), mice and print-
ers to the USB ports on the system rear panel.
Connecting to a network device
Connect one end of a network cable (RJ45 connector) to the LAN port on the
system rear panel and the other end to a hub, switch or router.
Connecting to a display
Connect one end of the supplied video cable to a TV or monitor and the other
end to the HDMI or VGA port.
Turning on the system
Plug the supplied AC adapter into the power outlet and then connect the other
end into the DC IN jack on the system rear panel. Press the power button on
the front panel to turn on the system.
1
2
3
4
1
2
3
4
6
