ZOTAC ZBOX
Using a dynamic IP (PPPoE connection)
1. Repeat Step 1-3 in the previous section.
2. Select “Obtain an IP address automatically” and click “OK”.
3. Click “Create a new connection” to start the NEW Connection Wizard.
4. Click “Next”.
5. Select “Connect to the Internet” and click “Next”.
6. Select “Set up my
connection manually”.
7. Select your connection
type and click “Next”.
8. Enter your ISP Name and
click “Next”.
9. Enter your User name and
Password. Click “Next”.
10. Click “Finish” to nish the
conguration.
11. Enter your user name and password. Click
“Connect” to connect to the internet.
Note: Contact your internet Service Provider (ISP) if you have problems connecting to the network.
Conguring audio output via an HDMI device
Follow the steps below to enable audio output via HDMI when connecting the
ZOTAC ZBOX to a TV or receiver via HDMI.
1. Access the Sound settings via the system
Control Panel.
2. Under Playback devices, click the display
device that corresponds with your HDMI
audio compatible display.
3. Click the “Set Default” button in the lower
right hand corner.
4. Click “OK” to exit the setup.

Zotac ZBOX series Specifications

General

Series	ZBOX
Processor	Varies by model (e.g., Intel Core i3, i5, i7, or AMD Ryzen)
Graphics	Varies by model (e.g., Intel UHD Graphics, NVIDIA GeForce GTX/RTX)
Memory	Varies by model (DDR4 SO-DIMM slots, capacity varies)
Storage	Varies by model (M.2 slots, 2.5" SATA bays, NVMe support)
Operating System	Varies by model (Windows)
Connectivity	Varies by model (Gigabit Ethernet, Wi-Fi, Bluetooth)
Ports	Varies by model (USB 3.1, USB Type-C, HDMI, DisplayPort, Audio jacks)
Power Supply	Varies by model (e.g., external power adapter, 65W-120W)
Dimensions	Varies by model (e.g., 210mm x 203mm x 62mm)
