Chapter 5 - Software Structure
Confidential and Proprietary Information of ZTE CORPORATION 53
F IGU R E 16 T HE INT ERF ACE M ODEL O F C AL L CON N E C T IO N S Y S T EM
MGC
H.248
C A L L
ICS
S O F T S W IT C H
DB
ZXMSG 5200
R04
R01
...
MPR
IP
HW
IP packet
ALC
HW
MGCP
The CALL module is located between a board physical layer (ICS/MPR/ALC)
and a H.248 protocol module. The CALL module is designed to shield the
protocol module from connecting to the physical layer directly, enabling
the protocol module to be transplantable. The CALL module also can shield
the protocol layer for boards. The module can be consistent with interfaces
for protocol modules as MGCP and H.248.
Call Connection Sub-Modules Functions
The whole call connection module consists of six sub-modules: AgCallCtl
information distribution sub-module, AlsCall subscriber processing sub-
module, RtpCall processing sub-module, Agtrace service tracing sub-
module and M05 module.
The AgCallCtl information distribution sub-module provides the following
functions:
 Power-on, initialization and applying for memory
 Distributing information and invoking call processing logic
 Applying and managing call data area; maintaining link table
 Data area backup
 Processing system events; active/standby changeover protection
The AlsCall subscriber processing sub-module provides the following
functions:
 Occupying and returning subscriber side resources, like resource
functional module, T network resource, SLN resource and data area
resource
