Zte ZXR10 2928E User Manual

ZXR102900ESeriesCongurationGuide
Figure3-7NetworkArchitectureofAutomaticCongurationFileDownloading
ThenetworkarchitectureisshowninFigure3-7.SettheTFTPserveraddressandversion
lenameontheDHCPserver.Forexample,settheTFTPserveraddressto10.40.89.78,
andsetthelenameto*.dat@zImage.Afterpoweredon,thesystemdownloadsZXR10
2918E.dat(assumethatthedevicetypeisZXR102918E)andzImagefromtheTFTP
server.Afterdownloadingthelesuccessfully,thesystemisrestarted.
3.7ConguringAutomaticSavingofaConguration
File
Note:
Thefunctionofautomaticsavingofacongurationlehelpsyoutouploadswitch
congurationstothebackend.
Theuploadedcongurationlesincludestartrun.datandtoPmac.dat.Whenthe
timesetbyperiodiscounteddownto0,theswitchuploadsthestartrun.datletothe
TFTPserveratalocaltimebetween00:00and00:01,anduploadsthetoPmac.datle
oneminutelater.Theautomaticallyuploadedlesarestoredintheflashsubfolderin
theupload/downloaddirectoryconguredbytheTFTPserver.Thenamesoftheles
respectivelyarestartrunmm_dd_yy.datandtoPmacmm_dd_yy.dat,where“mm”,
“dd”,and“yy”indicatethedateonwhichtheuploadoccurs.
3-10
SJ-20120409144109-002|2012-07-02(R1.0)ZTEProprietaryandCondential

Zte ZXR10 2928E Specifications

General

MAC Address Table Size	8K
Jumbo Frame	9K
Storage Temperature	-40°C to 70°C
VLAN	4K
Power Supply	AC: 100~240V, 50/60Hz
Dimensions	440mm x 44mm x 220mm
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 95% non-condensing
Power Consumption	< 30W
