- 25 -
C141500900.fm
User's manualAMBROGIO 3000
GB
Secondary settings
To perform this function, the time
needed for the lawn mower to
reach the secondary area follow-
ing the perimeter cable must be
programmed.
Follow indications below to calcu-
late the time:
1-Place the lawn mower out of
the recharging base directed
towards the output cable.
2-Press ON and CHARGE.
3-Record the time the lawn
mower needs to reach the
middle of the secondary area.
Important
If there is a setting for the rapid return
on the way to the secondary area, the
lawn mower must be manually directed
to the perimeter cable when it exits.
4-Press ENTER.
The display shows:
5-Press (+) Key and (-) Key to enter the
number of working cycles to be per-
formed in the main area, after which
the lawn mower will start mowing the
first secondary area. If there is no
secondary area enter "zero" (0).
6-Press (+) Key and (-) Key to modify
numerical values.
7-Press ENTER to save the number of
cycles.
8-Press ENTER.
The display shows:
9-Press (+) Key and (-) Key to enter the
time (in minutes) needed by the lawn
mower to reach the first secondary
area. If there is no secondary area
enter "zero" (0).
10-Press ENTER to save the time.
11-Press ENTER.
The display shows:
12-Press (+) Key and (-) Key to enter
the number of working cycles to be
performed in the main area, after
which the lawn mower will start mow-
ing the second secondary area. If
there is no second secondary area
enter "zero" (0).
13-Press ENTER to save the number of
cycles.
14-Press ENTER.
The display shows:
15-Press (+) Key and (-) Key to enter
the time (in minutes) needed by the
lawn mower to reach the second sec-
ondary area.
If there is no secondary area enter
"zero" (0).
16-Press ENTER to save the time.
SECOND AREA.1
N.OF CYCLES 00
SECOND AREA.1
TIME 00
SECOND AREA.2
N.OF CYCLES 00
SECOND AREA.2
N.OF CYCLES 00
IDM - 41500300400.tif
Secondary
area 1
Main area
Secondary
area 2
