- 28 -
C141500900.fm
User's manualAMBROGIO 3000
GB
CHECKING THE CUTTING DISC
Check cutting blades weekly.
Use a brush to eliminate possible incrus-
tations from the blades.
If necessary, reverse, sharpen or re-
place the disc.
CLAMPS AND CONTACT PLATES
Check weekly the contact clamps
(A) of the mower and the plates
(B) on the base, clean them with a
dry cloth. If black signs are evi-
dent on the clamps - indicating
bad electrical contact - verify the
position of the clamps on the
plates, when recharging of the
mower.
If corrosion signs are evident on
the clamps or on the plates, clean
them using fine abrasive paper.
CUTTING DISC - REPLACEMENT
1-Turn off the lawn mower.
2-Overturn the lawn mower on a
surface that doesn't damage
the protection.
3-Remove grass residues from
the disc screw.
4-Unscrew disc fastening
screws.
Danger - Attention
Mount the cutting disc with the
tabs facing the body.
IDM - 41500901800.tif
contact plates (B)
IDM - 41500903900.tif
contact clamps (A)
IDM - 4150090400.tif
