P-660 Series Support Notes

0000: 20 20 20 20 20 20

RAW DATA:

0000: 00 A0 C5 92 13 11 00 80-C8 4C EA 63 08 00 45 00 .........L.c..E.

0010: 00 28 35 0B 40 00 80 06-3C 79 C0 A8 01 02 C0 1F .(5.@...<y......

0020: 07 82 04 5C 00 50 00 BD-15 A8 4A D1 B5 80 50 10 ...\.P....J...P.

0030: 22 38 E8 ED 00 00 20 20-20 20 20 20 "8....

2. Trace WAN packet

• Disable the capture of the LAN packet by entering: sys trcp channel enet0 none

• Enable to capture the WAN packet by entering: sys trcp channel mpoa00 bothway

• Enable the trace log by entering:

sys trcp sw on & sys trcl sw on

• Display the brief trace online by entering:

sys trcd brief

• Display the detailed trace online by entering:

sys trcd parse

Example:

P-660> sys trcp channel enet0 none

P-660> sys trcp channel mpoa00 bothway

P-660> sys trcp sw on

P-660> sys trcl sw on

P-660> sys trcd brief

0 12367.680 MPOA00-R[0070] UDP 202.132.155.95:520->202.132.155.255:520

1 12370.980 MPOA00-T[0062] TCP 202.132.155.97:10261->192.31.7.130:80

P-660> sys trcd parse

---<0000>----------------------------------------------------------------

LAN Frame: MPOA00-RECV Size:1181/ 96 Time: 12387.260 sec

Frame Type: TCP 192.31.7.130:80->202.132.155.97:10270

Ethernet Header:

Destination MAC Addr = 00A0C5921312

Source MAC Addr = 00A0C5012345

Network Type = 0x0800 (TCP/IP)

IP Header:

IP Version = 4

Header Length = 20

Type of Service = 0x00 (0)

Total Length = 0x048B (1163)

Idetification = 0xB139 (45369)

Flags = 0x02

Fragment Offset = 0x00

Time to Live = 0xEE (238)

103
