P-660 Series Support Notes
Now let's look at Option 1 in Menu 15.1. Enter 1 to bring up this menu.
Menu 15.1.1 - Address Mapping Rules
Set Name= ?
Idx Local Start IP Local End IP Global Start IP Global End IP Type
--- --------------- --------------- --------------- --------------- ------
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Action= Edit , Select Rule= 0
Press ENTER to Confirm or ESC to Cancel:
We will just look at the differences from the previous menu. Note that, this screen is
not read only, so we have extra Action and Select Rule fields. Not also that the [?] in
the Set Name field means that this is a required field and you must enter a name for
the set. The description of the other fields is as described above. The Type, Local and
Global Start/End IPs are configured in Menu 15.1.1 (described later) and the values
are displayed here.
Field Description Option
Set Name
Enter a name for this set of rules. This is a required field. Please
note that if this field is left blank, the entire set will be deleted.
Rule1
Action
They are 4 actions. The default is Edit. Edit means you want to edit
a selected rule (see following field). Insert Before means to insert a
new rule before the rule selected. The rule after the selected rule will
then be moved down by one rule. Delete means to delete the
selected rule and then all the rules after the selected one will be
advanced one rule. Save Set means to save the whole set (note when
you choose this action the Select Rule item will be disabled).
Edit
Insert Before
Delete
Save Set
Select Rule
When you choose Edit, Insert Before or Save Set in the previous
field the cursor jumps to this field to allow you to select the rule to
apply the action in question.
1
Note: Save Set in the Action field means to save the whole set. You must do this if
you make any changes to the set-including deleting a rule. No changes to the set take
38
