4
Control Panel Features
ALARM SOUNDER
AND SPEAKER
COLOR DISPLAY
WITH TOUCH SCREEN
MICROPHONE
EMERGENCY
BUTTON / INDICATOR
HOME
BUTTON / INDICATOR
Lights WHITE when enabled for emergency alarms
Blinks WHITE during emergency alarm
Lights GREEN when ALL sensors are closed (ready to arm)
Not lit when ANY sensor is open (not ready to arm)
Lights RED while system is armed
Blinks RED during the Entry Delay
Blinks RED during an alarm
Blinks RED after an alarm while system is still armed
Indicator flashes during power outages
(system on battery backup)
Flashes GREEN when ALL sensors are closed (ready to arm)
Flashes ORANGE when ANY sensor is open (not ready to arm)
Flashes RED while system is armed
For voice communication
with the Central Station
Shows all system information, status,
programming, and functions as the keypad
Display cycles clock, calendar, and weather
(press to manually change)
Sounds all system local alarms,
voice prompts, system sounds, and
audio for 2-way voice communications
with the Central Station
Sensor Status
Arming Status
Alarm Memory
Power Outage
2GIG-CNTRL2
