2N IP Uni User Manual

Installation manual 2N® IP Uni
39 / 58
1.
2.
3.
4.
•
•
Tag Inserting/Replacing Instructions
2N
®
IP Uniprovides an intuitive, easy access to the name plates. The tags
are easy to insert and replace even without a manual. You need not
remove the front panel and thus are not exposed to the risk of loss of
components while replacing the tags.
Loosen the name plate screw using the wrench enclosed, for
example. You can open the name plate window like a door without
losing the tightened screw.
Remove the used or blank name tag and insert a new tag.
Close the name plate window and tighten the screw appropriately.
Check the click effect of the buttons: if the button fails to click
properly when pressed (when moved by approx. 0.5 mm), the tag is
too thick or thin. Make sure that the button clicks when you press it
on either end.
2.5 Extending Module Connection
2N
®
IP Uniallows to connect following extending modules:
Security Relay
Induction Loop
Security Relay
The2N
®
Security Relay(Part No.9159010) is used for enhancing security between the intercom
and the connected electric lock.The2N
®
Security Relayis designed for any2N IPintercom
model withfirmware versions 1.15 and higher. It significantly enhances security of the
connected electriclock as it prevents lock opening by forced intercom tampering.
Function:
The2N
®
Security Relayis a device installed between an intercom (outside the securedarea)
and the electric lock (inside the secured area). The2N
®
Security Relayincludesa relay that can
only be activated if the valid opening code is received from the intercom.
