3-26
Click Port > Link Aggregation > Create. The Link Aggregation Create Page opens.
Figure 3-28 Link Aggregation Create Page
The Link Aggregation Create Page includes the following fields:
Table 3-21 Link Aggregation Create Page item description
Item Description
Enter Aggregation
Group ID
Defines the group ID.
Manual Defines Manual Aggregation
Static Defines Static LACP Aggregation
To create a new link aggregation group:
1) Enter a LAG ID in the box field.
2) Select Link Aggregation Type (Manual or Static)
3) Select the ports to add to the group.
4) Click Apply.
Modifying Link Aggregation
The Link Aggregation Modify Page allows network managers to select or deselect port for the specific
LAG.
Click Port > Link Aggregation > Modify. The Link Aggregation Modify Page opens.
