Apply two thin layers of Cube Glue to the print pad in an area of 50 mm x 50 mm.6.
Select the checkmark to continue.
NOTE: For more information, refer to the section titled Applying Cube Glue.
NOTE: It may take several minutes to print the file.
When finished, remove the print pad and verify the Level Gap.7.
NOTE: If any adjustments are needed, perform this procedure again after
making the adjustments. Make sure all glue and plastic residues have been
removed prior to performing this procedure again.
Compare Print Jet Z-Gaps
Inspect the Z-Gap readings for each print jet. If any of the print jets have an incorrect Z-
gap, they will need to be leveled again.
NOTE: The Closed Z-Gap (A) and the Open Z-Gap (B) are two different
measurements but should be read together.
