-11-
7. Viewing Documentation
Start the TEST RESULTS function.
Using the arrow keys, you can scroll and choose a test log. Search forward or backward for a particular test.
There are up to 150 tests in the memory. The date, time and ID code of a test (if activated in the configura-
tion) are displayed
With the # key, you can switch to the last test that was performed
With the START key, the test is displayed
The test data follow. Press any key (except STOP) to display other values measured.
The device displays the ID code entered for measurement.
Date and time of a test are displayed.
Date and time of test was performed.
The evaluation of the selected test is displayed:
PASS: tested system passed integrity test.
FAIL: tested system failed integrity test.
NOT CARRIED OUT: test was not carried out.
The number of the applied test program and the specified filter type are displayed
Type of test is displayed
Test diffusion rate is displayed
Using the * key, you can access other values:
- Pressure drop overall, a negative value signifies a pressure increase
- Pressure drop/min
- Diffusion rate
TEST RESULTS?
PROCEED >
TEST RESULTS?
PROCEED >
3/18/2014 18:00
TEST ID 7
#
START
TEST DATA
>
USER CODE
55 >
DATE 29.01.2014
TIME 17:52
RESULT
PASS >
TEST PROGRAM Nb. 1
01x10“0.20 >
TEST-METHOD
PRESSURE DROP TEST
DIFFUSION RATE
10.0ml/min
#
0.0ml/min
OTHER VALUES *
