3M 101 Series User Manual

Ambient Conditions
Temperature Range 41° – 104 °F (5 - 40 °C)
Maximum Humidity Limit 95% relative humidity
Polution Degree 2
Altitude limit (max.) 6,562 ft (2000 m)
Electrical Data
Battery Pack 4x 1.2 VDC NiMH battery pack / 4.8 VDC pack
Battery Capacity 200 mAhr, 4.8 V
Time Taken To Recharge The Battery 4 hrs
Operating Time For
Continuous Test Operation (The Yellow LED Flashes) 6 hrs
Normal Operation 7 hrs - 12 hrs
Data Storage (With Fully Charged Batteries) 4 months / 25 °C
Power Supply (adapters for various countries available) 100 - 240 VAC, 50/60Hz, / 9.0 VDC 1000 mA SELV output
Charger Socket Cylindrical connector 5.5mm x 2.1mm, Negative pole outside
Data Transmission
Wireless (printer only) BlueTooth
Wired connection mini-USB cord
Programs
Maximum Number Of Test Programs 19
Maximum Number Of Test Reports Memorized 150
Pressure Measurement
Measurement Range 0…60 psi (0 ... 4137 mbar)
Accuracy relative at 68 °F (20 °C) < 0.2%
Temperature Error + 0.29 psi (± 20 mbar) for ± 15 Kelvin
Compressed Air Connector
Staubli
®
RBE 03.6150
Case
Material Of Case ABS
Compatibility Of Case fuel, sea-water, detergent, light alkalis/acids, alcohol
Incompatibility Of Case benzene, acetone
Dimensions 210 x 105 x 45 mm
Weight 1.1 lb. (500 gram)
Miscellaneous
Display 2 x 20 digits
LED Indicators red, green, yellow
Recharge Control Light red
Keyboard 16-key touch sensitive Polycarbonate Film
15.Technical Facts
15.1 Device Features
-23-

3M 101 Series Specifications
