-13-
Programmed test pressure.
Programmed test time.
Programmed test cartridge diffusion rate at above pressure.
Programmed test system upstream volume.
Programmed test cartridge quantity.
TEST PRESSURE
12.00 psi
TEST TIME
120 sec >
DIFFUSION RATE
60.0ml/min
UPSTREAM VOLUME
1860 ml
NO. OF CARTRIDGES
1
8. Selecting Other Main Menu Functions
After being switched on, the 3M Series Integrity Test Device first calls up the filter test function. To carry out another function, the operator must
first halt the current filter test program.
Device display indicates it is at test function program #1.
Press STOP to exit current programming activity.
Return to the main function menu.
TEST PROGRAM NB 1
ENTER >
TEST PROGRAM ?
PROCEED >
STOP
