3MtOverhead Projector 2000
Illustrated Parts Breakdown
6
E 3M IPC 2000
Section 4
LAMP MODULE ASSEMBLY--FSY SPARE PART KIT
1
2
NOTE: Screws, Nuts, Bolts, Clips, and etc. are contained in Hardware Kit 78-8062-1150-0.
33
Section 4
LAMP MODULE ASSEMBLY--FSY SPARE PART KIT
Item No. Part Number Description Qty
1 78-8062-1115-3 LAMP MODULE ASSEMBLY--FSY Spare Part Kit 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 78-8057-4163-0 LAMP, Projection, FSY, 400W, 240V 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 78-8057-4056-6 SHAFT, Lampholder 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
