3MtOverhead Projector 2000
Illustrated Parts Breakdown
2
E 3M IPC 2000
Section 0
OVERVIEW
Base and Base Top Assembly
(See Section 2 )
Top Shroud Assembly
(See Sections 6 and 7 )
Lamp Assemblies
(See Sections 3, 4 and 5 )
Post Pivot Assembly
(See Sections 11 and 12 )
Mirror Housing Assembly
Projection Lens and Focus
Mechanism
(See Sections 8, 9 and 10 )
Stage Cover Assembly
(See Section 14 )
To Section One
To Next Page
