NA - ENG
April 2017
3M-Matic
™
Accuglide 3 - 2 Inch Taping Head
Page 3
AccuGlide
™
3
High Speed - 2 Inch Upper and Lower Taping Heads consist of:
Qty. Part Name
1 Taping Head Assembly
1 Tape Drum and Bracket Assembly
1 Hardware and Spare Parts Kit
1 Threading Tool
General Information
This instruction manual covers safety aspects, handling and transport, storage, unpacking,
preparation, installation, operation, set-up and adjustments, technical and manufacturing
speci cations, maintenance, troubleshooting, repair work and servicing, electric diagrams,
warranty information, disposal (ELV), a glossary with a de nition of symbols, plus a parts
list of the 3M-Matic™ Accugllide 3 (2 inch) 3M Industrial Adhesives and Tapes Division
3M Center, Bldg. 220-5E-06 St. Paul, MN 55144-1000 (USA) Edition April 2017/
Copyright 3M 2017. All rights reserved The manufacturer reserves the right to change
the product at any time without notice.
How to use this Manual
The manual is an important part of the machine; all information contained herein is
intended to enable the equipment to be maintained in perfect condition and operated
safely. Ensure that the manual is available to all operators of this equipment and the
manual is kept up to date with all subsequent amendments. Should the equipment be
sold or disposed of, please ensure that the manual is passed on with the machine.
Electrical and pneumatic diagrams are included in the manual. Equipment using PLC
controls and/or electronic components will include relevant schematics or programs in
the enclosure (or will be delivered separately as needed)
Keep the manual in a clean and dry place near the machine. Do not remove, tear or
rewrite parts of the manual for any reason. Use the manual without damaging it.
However, if the manual has been lost or damaged, ask your after sale service for a new
copy (if it is possible, please have the manual name, part number, and revision information
and/or model/machine name, machine type, and serial number) that are located on the
identi cation plate (For example: Model - Accuglide 3 - 2” - Type 10800 -
Serial Number 13282).
Note: All the important warning notes related to the operation of the machine are
identi ed by the symbol:
Updating the Manual
Modi cations to the machine are subject to manufacturer’s internal procedures.
The user may receive pages or parts of the manual which contain amendment made
after its rst publication. The user must use them to update this manual.
