Receiving And Handling
  After the taping head assembly has
  been unpackaged, examine the unit
  for damage that might have occurred
  during transit.  If damage is evident,
   le a damage claim immediately with
  the transportation company and also
  notify your 3M Representative.
Installation Guidelines
  The taping head assembly can be
  used in converting existing or in
  custom made machinery.
  It can be mounted for top taping
  or bottom taping.  Refer to “Box Size
  Capacities,” as well as Figure 2-1
  in the Speci cations section, for
  following points making installations:
 Important – Always conduct a hazard
    review to determine appropriate
 guarding requirements when the
    installation is in an application
 other than 3M-Matic™ equipment
  1.  The box conveying system
  must positively propel the box in
  a continuous motion, not exceeding
  0.50 m/s [100 feet per minute],
  past the taping head assembly
  since the box motion actuates
 the taping mechanism.
  2.  If a pusher/cleated conveyor is used,
    steps should be taken in conveyor to
    prevent pusher from contacting apply-
    ing or bu  ng roller arms (resulting in
    damage to taping head).
 3. Figure 2-1 illustrates the typical
    mounting relationship for oppos-
    ing taping head assemblies to
    allow taping of box heights
    down to 90mm [3-1/2 inches].
    To tape box heights down to
    70mm [2-3/4 inches], the taping
    heads must be completely
    staggered so only one tape seal
    is being applied at one time.
 Note – AccuGlide™ 3 High Speed Upper
    Taping Head is supplied with a bu  ng
    arm guard. Adjustments to guard may
    be required to install taping head into
    some older design case sealers.
  4.  Mounting studs are provided with the
    taping head, but special installations
    may require alternate mounting means.
  5.  Box hold-down/guide skis should be
    provided and taping head mounted so
    that side plates are 6mm [1/4 inch]
    maximum away from the ski surface on
    which the box rides.
Tape Leg Length
  Taping heads are factory set to apply
  standard 70mm [2-3/4 inch] tape legs.
  The heads can be converted to apply
  50mm [2 inch] tape legs if but both upper
  and lower heads must be set to apply the
  same tape leg length.  See “Adjustments –
  Changing Tape Leg Length from 70 to
  50mm [2-3/4 to 2 Inches].”
  Also, conveyor speed at which the
  product moves through taping heads
 a ects the leading and trailing tape leg
  length. See “Adjustments section -
  Leading Tape Leg Length Adjustment.”
Tape Width Adjustment
  Taping heads are factory set to apply
  48mm [2 inch] wide tape.  If it is
  necessary to align the tape or to apply
  narrower tapes, refer to “Adjustments –
  Tape Web Alignment” set-up procedure.

CAUTION
•  To reduce the risk associated with
 muscle strain:
-  Use proper body mechanics when
  removing or installing taping heads
  that are moderately heavy or may be
  considered awkward to lift
• To reduce the risk associated with
sharp blade hazards:
-   Keep hands and  ngers away from
tape cuto  blades under orange blade
guards.  The blades are extremely sharp.

WARNING
Installation
