10 Standards
Appendix A: Specifications
*All specifications subject to change
Standards
ANSI S1.4 1983 (R 2006)
ANSI S1.43 1997(R 2007)
IEC 61672-1 (2002)
IEC 61010-1 (2010)
CE mark
Mechanical characteristics
Electrical characteristics
Housing
ABS/polycarbonate
Size
(Length x Width x Thickness)
16.5 cm x 6.1 cm x 2.3 cm
6.5” x 2.4” x .9
Weight
125 g (4.4 oz)
Tripod Mount
Accepts a ¼20 screw (located on bottom,
backside of the instrument).
Battery type
Lithium polymer battery (1000 mAh), rechargeable.
Battery life
3 yr or 500 charge cycles
Battery runtime
35 hours with LEDs activated (minimum hours)
(40 hours, typical )
50+ hours without LEDs activated
Microphone
Frequency range
Omni-directional ; Class/Type 2;
1/2” diameter; electret condenser
31.5 to 8000 Hz
