Page #31 background image
3M™ MicroTouch™ Controller EX USB Reference Guide 31
3M Touch Systems, Inc. Proprietary Information -- 29489v05
Technical Specifications
The controller specifications listed below were validated in test systems containing 3M
Touch Systems components. These specifications may not be valid if configured with
components from suppliers other than 3M Touch Systems. All components in the
manufacture of electronic controllers are RoHS Directive compliant (2002/95/EC).
Physical Dimensions
Uncased 3.50 in. x 2.30 in. x 0.45 in. (88.9 mm x 58.4 mm x 11.4 mm)
Cased 3.75 in. x 2.50 in. x 0.90 in. (95.3 mm x 63.5 mm x 22.9 mm)
Board Level Functions
Power 5 VDC (87 mA typical, 100 mA maximum); 5% regulation 50 mV
pp
maximum ripple and noise
Regulatory Requirements
CE Compliant
Radiated Emissions – EN 55022:1998 Class B Compliant
AC Mains Conducted Emissions – EN 55022:1998 Class B Compliant
Telco Lines Conducted Emissions N/A N/A
RFI – EN 61000-4-3 / ENV 50140 Class A Compliant
CRFI – EN 61000-4-6 N/A Cable < 3 meters long N/A
Class A < 80% Screen Area
Class B >
80% Screen Area
EFT (Burst Immunity) – EN 61000-4-4 Class B Compliant
ESD Susceptibility – IEC 61000-4-2 Class 1 Compliant
Surge – EN 61000-4-5 Class B Compliant
Harmonics – EN 61000-3-2 Class A Compliant
Flicker – EN 61000-3-3 Compliant
Power Frequency Magnetic Field – EN 61000-4-8 N/A N/A
Voltage Dips – EN 61000-4-11 Class B < 5% V
Class C < 70% V Compliant
Voltage Interruptions – EN 61000-4-11 Class C Compliant
FCC Class B / CISPR22 Class B Class B Compliant
VCCI Class B ITE Emissions (Japan) Class B Compliant
AS/NZS 3548:1995/CISPR 22 Class B ITE Emissions
(Aus.)
Class B Compliant
UL/cUL Compliant
