TroubleshootingGuide
20|Page



Table4–510(T‐D2)DipswitchSettings:UPPERBANK
No. Function ONposition OFFposition
1 Gastype Propane Disable
2 NaturalGas Disable
3 Allowadjustmentsoffanmotorspeed Enable Disable(Default)
4 FM+,FM++,FM+++Indoor510(T‐D2‐IN)
 No.4
OFFposition ONposition
No.5 OFFposition 0% +6%
ONposition +12% +18%
Outdoor510(T‐D2‐OS)
 No.4
OFFposition ONposition
No.5 OFFposition 0% +4%
ONposition +8% +12%
5
6 N/A N/A N/A(Default)

Table5.4‐510(T‐D2)DipswitchSettings:LOWERBANK
No. Function ONposition OFFposition
1 Parent/ChildsettingforEasy‐Linksystems Parent Child(Default)
2 Modeltype Indoor510(T‐D2‐IN)
(Default)
Disable
3 Outdoor510(T‐D2‐OS)
(Default)
Disable
4 Outputtemperaturesettings(Default122˚F)

5
6
Upperbankofdipswitches
Lowerbankofdipswitches
Figure16
