A.O. Smith 310 - CLEANING COMBUSTION COMPONENTS

TroubleshootingGuide
26|Page

CLEANINGTHECOMBUSTIONCOMPONENTS
Procedureforcleaningthefan,burner,FlameSensorandAFR,asusedbyallServiceRepresentatives.

1) TOOLS
‐Gatherthefollowingmaterialstogether:
a. Degreaserinapumpactionbottle,Sandpaper,Philips ScrewDriver,Needle‐NosedPliers,Duct
Tape,Flashlight,AirCompressor,ShopVacuum,3xTowels

2) POWER
‐Disconnectpowertoyourunitbyeitherunpluggi ngitfromthewalloutlet,orbythecircuit
breaker,dependingonthesetup.

3) GAS
‐Shutoffthegassupply.

4) FRONTCOVER
‐Removethefrontcover.

5) MANIFOLDPLATE/GASVALVEASSEMBLY
‐
a. Removethemanifoldplatescrews.TheyarewidepanheadPhilipsscrews,locatedonthe
edgesofthestampedmetalplateofthegasmanifold

b. Removethebrassgasvalvescrew.
c. RemovethewireholdingtheEasy‐Linkwiresinplace.
d. Disconnecttheclearplastictubefrombeneaththecombustionchamber
e. Gentlyliftupthemanifold&gasvalveassemblytodislodgeitfromthegasinlet,andgentlyletit
hang.
i. Thereisasmallfilterscreeninthebottomofthegasinlet.Donotloseit.








Figure25
Figure26
