CHECKINGTHEOVERHEATCUTOFFFUSE(OH CF):
1) LocatethewhiteOHCFwhichwrapsaround
theheatexchanger.
2) Findthewhiteclipattheendofthetwoblue 
braidedwirescomingfromtheOHCF.
3) Unplugtheconnection.
4) TestforcontinuityattheendoftheOHCF
withanohmmeter.Ifthereiscontinuity,the

OHCFisstillintact.Reconnecttheplug.If
thereisnocontinuity,theOHCFhasbeen
compromised.Ifcompromised,contactthe
TechnicalServiceDepartmentforfurther
assistance.
5) Ifanohmmeterisnotavailable,jumptheplugconnectionontheoppositesideoftheOHCF
withawire,paperclip,
orothermetalmaterial.
6) Restorepowerandtestunit.Beverycautiouswiththisstep.Donottouchthejumperor
otherelectricalcomponents.
7) Iftheunitfiresup,itshowsthattheOHCFhasbeencompromisedandtheproblemwaswith
theOHCF.Ifso,contacttheTechnical
ServiceDepartmentforfurtherassistance.Iftheunit
doesnotfireup,itshowsthatthecauseofthe111or121errorcodeissomethingelse.
Continuewiththe111or121errorcodesectionsofthisguideforfurthertroubleshooting. 


























Figure23
Figure22
