Page #93 background image
T-H2-DV/T-H2-OS Service Manual
Ver. 1.01
93
CONFIDENTIAL
14. Parts list
Item # Part # Description Common parts for other models
001 EKH5B Case assembly (DV)
002 EKH5M Front cover (DV)
003 EV00K Intake air port assembly
004 EM335 Brackets T-M50
005 EKH5D Back guard panel
006 EKJ64 Junction box
T-K3, T-K3-Pro, T-K3-SP/OS, T-KJr2-IN/OS, T-K4-IN/OS,
T-D2-IN/OS, T-M50, T-M32
007 EX13M Rubber bush
008 EM484
Overheat-cut off-fuse for
combustion chamber
T-M32
009 EKK22 Fastener T-M32
010 EKH23 Condensate drain port
011 EKH5K Duct
012 EKH4G Duct gasket A
013 EKH4K Duct gasket B
014 EKH73 Duct cover plate
015 EKH5C Case assembly (OS)
016 EKH61 Front cover (OS)
051 EW000 Screw M4×12 (W/Washer) *
052 EW002 Screw M4×10 (Coated) *
053 EX010 Pan screw M4×10 *
054 EW02B Screw M4×10 *
055 EW023 Pan screw M3×10 *
101 EKH5W Burner assembly T-K4-IN/OS, T-D2-IN/OS
102 EKK2X Burner gasket
T-K3, T-K3-Pro, T-K3-SP/OS, T-KJr2-IN/OS, T-K4-IN/OS,
T-D2-IN/OS
103 EKK0G Burner holder gasket
T-K3, T-K3-Pro, T-K3-SP/OS, T-K4-IN/OS, T-D2-IN/OS,
T-M50
104 EKK2V Burner window
T-K3, T-K3-Pro, T-K3-SP/OS, T-KJr2-IN/OS, T-K4-IN/OS,
T-D2-IN/OS, T-M50, T-M32
