2-3
Chapter 2: Motherboard information
Connectors/Jumpers/Slots Page
1. DCpowerconnector(DC_PWR2) 2-17
2. PS/2keyboard/mouseconnector(6-pinKBMS) 2-21
3. CPUandchassisfanconnectors(4-pinCPU_FAN,4-pinCHA_FAN) 2-18
4. SerialATA3.0Gb/sconnector(7-pinSATA3G_1) 2-26
5. SerialATA6.0Gb/sconnectors(7-pinSATA6G_1/2) 2-22
6. COM1Ring/+5V/+12Vselection(COM1_VSET) 2-14
7. Serialportconnectors(10-pinCOM1,COM2) 2-24
8. DigitalI/Oconnector(10-pinDIO) 2-20
9. LVDSconnector(30-pinLVDS) 2-19
10. InverterBacklightControlmodeselection(3-pinLJ3) 2-15
11. Invertervoltageselection(3-pinLJ2) 2-14
12. LVDSpanelvoltageselection(3-pinLJ1) 2-14
13. Backlightinverterpowerconnector(5-pinINV) 2-25
14. Frontpanelsystempanelconnector(10-1pinF_PANEL) 2-21
15. Chassisintrusionconnector(4-1pinCHASSIS) 2-20
16. Internalspeakerconnector(4-pinSPEAKER) 2-22
17. ClearRTCRAM(CLRTC) 2-13
18. Intel
®
LGA1150CPUsocket 2-6
19. Intel
®
MEJumper(3-pinDIS_ME) 2-15
20. SO-DIMMslots 2-11
21. VGAconnector(16-pinVGA) 2-18
22. Full/HalfsizeMiniCard(mSATA)(MINICARD2)
HalfsizeMiniCard(PCIe+USB)(MINICARD1)
2-22
23. AUXpowerLED(SB_PWR)
MainpowerLED(VS_PWR)
2-1
24. Batteryconnector(2-pinBATTERY1) 2-25
25. Audioamplierconnector(4-pinAMP_CON) 2-18
26. Frontpanelaudioconnector(10-1pinAAFP) 2-19
27. SATApowerconnector(4-pinSATA_PWR) 2-17
28. USB2.0connectors(10-pinUSB34,USB56,USB1112) 2-23
29. SPIashprogrammableconnector(8-pinSPI_1) 2-23
