3-4
EMB-H81B
3.3 Advanced menu
The Advanced menu items allow you to change the settings for the CPU and other
system devices.
Be cautious when changing the settings of the Advanced menu items. Incorrect
eld values can cause the system to malfunction.
3.3.1 S5 RTC Wake Settings
This item allows you to enable the system to wake up from S5 state using an alert
event.
Wake system with Fixed Time [Disabled]
Allows you to enable or disable the system’s wake-on alert event. When enabled,
the system wakes up on the specied time. Conguration options: [Enabled]
[Disabled]
Wake system with Dynamic Time [Disabled]
Allows you to enable or disable the system’s wake-on alert event. When enabled,
the system wakes up on the current time plus the specied wake-up minute.
Conguration options: [Enabled] [Disabled]
3.3.2 Dynamic Digital IO
The items in this menu allows you to congure the Digital IO as input or output and
Digital IO Output as high or low.
GPIO 0~3 [Input]
Allows you to set the GPIO 0~3 as Input or Output. Conguration options: [Input]
[Output]
Select Screen
Select Item
Enter: Select
+/- Change Opt.
F1 General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.16.1240 Copyright (C) 2013, American Megatrends, Inc.
Enable Spread
Spectrum function
for BCLK, DMI, PEG,
PCIe,PCI33, SATA,
USB3.
S5 RTC Wake Settings
Dynamic Digital IO
ACPI Settings
Trusted Computing
 CPUConguration
 SATAConguration
 PCH-FWConguration
 AMTConguration
 USBConguration
 NCT6791DSuperIOConguration
NCT6791D HW Monitor
Aptio Setup Utility - Copyright (C)2013 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
