Aaeon EMB-H81B - Specifications

EMB-H81B
1-2
1.3 Specifications
SYSTEM
CPU
LGA1150 socket for Intel
®
4
th
Generation Core™ i7 / Core™ i5 /
Core™ i3, Pentium
®
/ Celeron
®
processors
Supports Intel
®
CPU Max. 65W TDPs
Chipset
Intel
®
H81 Express Chipset
Memory
2 x SO-DIMM (8GB per DIMM), max. 16GB, non-ECC DDR3 1600
/ 1333 MHz
Dual-channel memory architecture
Graphics
Intel
®
HD Graphics
I/O Chipset
NCT6791D
Storage
Intel
®
H81 Express chipset supports 2 x SATA 6Gb/s, 1 x SATA
3Gb/s
Ethernet
2 x Realtek
®
8111G PCIe Gigabit LAN
Audio
Realtek
®
ALC887 with Amp.
TPM
InneonSLB9635TT1.2
Expansion slots
1 x PCI Express 2.0 [x1] slot
1 x Half size Mini Card (PCIe +USB)
1 x Full/Half size Mini Card (mSATA 3.0Gb/s)
BIOS
64Mbit Flash ROM, AMI BIOS
H/W Monitor
Temperature monitor on CPU/Chassis
Voltage Monitor on Vcore/5V/12V
Fan Monitor on CPU/Chassis
Watchdog Timer
1~255 steps by software program
Wake on LAN
Yes (WOL/PXE)
Smart Fan Control
CPU Fan/Chassis Fan
Power State
S3, S4, S5
GRAPHICS
Graphics Chipset
Intel
®
HD Graphics
Graphics Multi-
Display
VGA+HDMI, VGA+DP, VGA+LVDS, HDMI+DP, HDMI+LVDS,
DP+LVDS
VGA
Up to 1920 x 1200 @ 60 Hz
HDMI
Up to 4096 x 2160 @24 Hz / 2560 x 1600 @60 Hz, with Digital
Audio
DisplayPort
Up to 4096 x 2160 @24 Hz / 3840 x 2160 @60 Hz, with Digital
Audio
LVDS
Up to 1920 x 1200 @60 Hz, Dual Channel 18/24 bit
Backlight Control
Voltage / PWM
(continued on the next page)
