1-3
Chapter 1: General information
I/O
Storage
2 x SATA 6Gb/s
1 x SATA 3Gb/s
1 x Full / Half size Mini Card (mSATA)
1 x Half size Mini Card (PCIe+USB)
USB
2 x USB 3.0 ports(Rear IO),
6 x USB 2.0 ports (2 ports at the back panel, 4 ports at mid board)
Display I/O
1 x LVDS, 1x HDMI, 1x DP, 1x VGA
Audio I/O
Mic-in, Line-out, AAFP at internal connector for 2 additional chan-
nel(default Line-out, Mic-in), speaker
LAN I/O
2 x RJ-45
Serial port
1 x RS-232 (mid board)
1 x RS-232/422/485 supports 5V/12V/RI option (mid board)
PS/2 port
1 x keyboard / Mouse with PS/2 for wafer header
DIO
8-bit Digital I/O interface (In/Out programmable)
FAN
1 x CPU Fan connector (4-pin)
1 x Chassis Fan connector (4-pin)
ENVIRONMENT, POWER, & ME
Power requirement
12~24V wide-range voltage input back panel DC jack (5.5/2.5mm)
2 x 2 pin internal power connector
4-pin internal power connector
Power Compliance
Compliant with EuP / ErP
Operating
Temperature
0~60°C
Operating Humidity
0% ~ 90%RH, non-condensing
Certificate
CE & FCC
Form Factor
20mm Thin Mini ITX Form Factor, 6.7”x 6.7” (170mmx170mm)
Half-height (25.54mm) I/O shield
Weight
1.1 lb (0.5 Kg)
PLACEMENT
Back I/O ports
1 x DC Jack
2 x USB 2.0 ports
1 x HDMI port
1 x DisplayPort
2 x LAN (RJ45) ports
2 x USB 3.0 ports
1 x Audio jack (Mic-In) pink connector
1 x Audio jack (Line-Out) green connector
(continued on the next page)
