EMB-H81B
1-4
PLACEMENT
Internal I/O
connectors
2 x boxer header for COM (1 x RS-232, 1 x RS-232/422/485)
1 x VGA
1 x 6-pin (2x3) PS/2 Keyboard and mouse connector
1 x LVDS connector
1 x LVDS 3.3V /5V jumper
1 x LCD DC / PWM mode jumper
1 x LCD backlight connector (inverter)
1 x LCD backlight 12V /5V jumper
1 x Digital I/O box header
1 x 4 PIN (2x2) internal power connector
1 x 4 PIN CPU Fan connector
1 x 4 PIN Chassis Fan connector
1 x Front Panel connector
1 x AAFP
1xSpeakerfor2W/4Ω
1 x Chassis Intrusion follow ASUS pin out
1 x pin header for Buzzer
1 x CLTRC (Clear CMOS) jumper
1 x PCIe x1 slot
1 x Full / Half size Mini Card (mSATA)
1 x Half size Mini Card (PCIe+USB)
2 x SATA 6Gb/s
1 x SATA 3Gb/s
2 x USB 2.0 connectors support additional 4 USB ports (2.00 mm)
OTHERS
OS Support
Windows 7 32 bit
Windows 7 64 bit
Windows 8 32 bit
Windows 8 64 bit
Linux Fedora
Accessories
1 x SATA cable
1 x SATA power cable
I/O Shield
Support DVD
NOTE: Specicationsaresubjecttochangewithoutnotice.
