1. INTRODUCTION
This manual describes how the AD-8923-BCD remote controller works and how to get the most out of it
in terms of performance.
Read this manual thoroughly before using the AD-8923-BCD and keep it at hand for future reference.
1.1. Features
Connecting the AD-8923-BCD remote controller to a weighing instrument will enable transmission of RS-
232C weight data from the weighing instrument to a PLC using BCD output.
Displays the weight data transmitted from the weighing instrument.
Can change the weighing speed of the AD-4212C/D/F, perform sensitivity adjustment with the AD-
4212C/D/F using an external weight and share the power supply with the AD-4212C/D/F.
Note
When connected to the following instruments, power can be supplied to both instruments
by plugging the AC adapter into either the weighing instrument or the AD-8923-BCD.
(Both instruments can have their AC adapter connected at the same time.)
Compatible models: AD-4212C/D/F, FZ, FX, GX-A, GF-A, GX-M, GF-M, GX-L, GF-L, HR-AZ,
HR-A (Refer to “3.3. Turning the power on”)
