2. DESCRIPTION OF EACH PART

Note

When the AD-8923-BCD is to be built into a

weighing system, be sure to ground the FG

terminal.

Please confirm that the AC adapter type is

correct for your local voltage and receptacle

type.

See the note below.

Display

Keys

Rear View

AC adapter

input jack

DC input terminal

BCD connector

FG terminal

RS-232C connector

(D-Sub 9-pin)

AD8

923

AD8923 AD8923

AD8923

Accessories

BCD plug 1 pc.

AC adapter 1 pc.

AD adapter

ID label

Attach the identification sticker for your

model to the AC adapter as shown.
