8.1. Applicable Instruments
The AD-8923-BCD functions in two ways as follows, depending on the weighing instrument used:
A remote controller that displays the weighing data and remotely controls the weighing instrument.
A remote display that displays the weighing data.
Available key operations depend on the weighing instrument used. (Refer to “Table 2”)
Table 1 Applicable weighing instruments and what is required
Weighing instrument
What is required to connect to
a weighing instrument
Option for the instrument
Communications cable (Length 2 m)
AD-4212C, AD-4212D
None
(D-Sub 9-pin)
None
(Use the cable provided for
the AD-4212C/D) *1
AD-4212F
None
(D-Sub 9-pin)
AX-KO3590-XXX *2
AD-4212A/B, GX,
GF, GX-K, GF-K, GP,
GR, MC
None
(D-Sub 25-pin)
AX-KO1710-200
GX-A, GF-A, GX-M,
GF-M, GX-L, GF-L,
FZ, FX, EK-i, EW-i,
EK-L, BM, GH, HR-i,
HR-AZ, HR-A
None
(D-Sub 9-pin)
AX-KO2741-180
EJ, HV-C, HV-C P,
HW-C, HW-CP
OP-03
(D-Sub 9-pin)
AX-KO2741-180
HV-G, HV-W P,
HW-G, HW-WP
None
(DIN 8-pin)
AX-KO1786-200
FG-L, FG-M
OP-23
(DIN 8-pin)
AX-KO1786-200
FS-i, SC, SE, SW
OP-03
(Discrete wire)
AX-KO3285-320
*1: - When connecting to the AD-4212C/D, use the cable provided as a standard accessory
for the AD-4212C/D.
- The part number for standard accessory cable for the AD-4212C is AX-KO3590-1000 (10 m).
- The part number for standard accessory cable for the AD-4212D is AX-KO3590-200 (2 m).
*2: For “XXX”, choose from 200 (2 m), 500 (5 m), or 1000 (10 m).
