GX-A Series/GF-A Series Communication Manual 40 / 41
Classification
item
Setting item Setting
value
Contents, usage
■
PC
Printer
or
Connection
destination
External display
and stream
output
600 bps
1200 bps
■
2400 bps
4800 bps
9600 bps
19200 bps
Baud rate
38400 bps
■
7 bit EVEN
7 bit ODD
Data bit, parity bit
8 bit NONE
■
CR LF
Terminator
CR
CR: ASCII 0 Dh code
LF: ASCII 0 Ah code
■
A&D Standard format
DP format
KF format
MT format
NU format
Data format
CSV format
Refer to "7-2. Weighing
data format"
■
No limit
Timeout
Limited to 1 second
Select waiting time during
command reception
Off
Serial
interface
AK、error code
■
On
Refer to "8-2. The <AK>
code and error codes"
■
Quick USB ALL
Quick USB NU
USB operation mode
Bidirectional USB
virtual COM
See "6-1. Quick USB mode"
See "6-2. Virtual COM mode"
■
A&D standard format
NU format
CSV format
USB
Interface
USB
Data format
TAB format
Refer to the CX-A / GF-A instruction manual
□ “■” Factory setting.
…
