A&D HC-3Ki - 10-3. ACAI Manual Operation

36
 Data Length and Parity
03
7 bits, even parity.
1
7 bits, odd parity.
2
8 bits, non parity.
 “f-07” and “f-08” are for factory use and should be “0”.
F-09-X ½ key
 Operation mode for the ½ key
03
Operating as a key to display and/or change comparator
upper and lower limits.
1
Operating as M- key to subtract Count data from M+
memory.
2
Operating as a key to toggle the weighing unit between “lb”
and “g”.
 Decimal Point and RS-232C Output
00003
Decimal point: “.”
Header for stable weight data: “ST”
Acknowledgment of command: <ACK><C
R
><L
F
>
Select the decimal point “.” or ” ,” and output
format for RS-232C. Set 0 or 1 for each bit.
Decimal point: “0” = ”.”
“1” = ”
,”
Header: “0” = “ST,+001.2346 kg”
“1” = “WT,+001.2346 kg”
Acknowledgment: “0” = ”<ACK><C
R
><L
F
>”
“1” = ”<ACK>”
 “f-10”, “f-11” and “f-12” are for factory use and should be “0”.
f-06-05
f-09-01
F-09-01=2 is for
USA version
only.
0000
ST/WT
N.A.
Decimal
ACK Point
f-09-02
