48
If the command is S , T or Z , the scale will send a second acknowledgment
<ACK><C
R
><L
F
> or <ACK> (see F-Function “f-09-02”) when the command
operation is completed.
If an error occurs, the scale will send an error code.
The error format is
EC , EnC
R
L
F
, “n” being error number.
En Definition Notes
E0 Communication Error Parity error, framing error, etc.
E1 Undefined command Error Command does not exist for the scale.
E2 Scale not ready Error.
The scale is not in a state where a command
could be expected.
E4 Too many characters Error Command contains too many characters.
E6 Format Error Command contains invalid characters.
E7 Out of range Error
Value is out of range. Tare weight is more than
the capacity, etc.
Data Format
Examples below are for f-09-02=”0000”. <ACK>=06H.
Store unit weight and other value in use (according to f-01-05).
Command E , 1 2 C
R
L
F
Stores to id-12. (E,000012C
R
L
F
is acceptable.)
Reply ACK C
R
L
F
ID Number
Command ? I D C
R
L
F
Reply ID,000012C
R
L
F
PCS (Count ) Data
Command ? Q T C
R
L
F
Reply QT,+00001234
[
PCC
R
L
F
Stable Positive Data
US, -00005678
[
PCC
R
L
F
Unstable Negative Data
OL,+99999999
[
PCC
R
L
F
‘E’ display
Weight Data
Command ? W T C
R
L
F
Reply ST,+001.2346
[
kgC
R
L
F
Stable Positive Data
ST, -002.7255
[
lbC
R
L
F
Stable Negative Data
US, -0012.346
[
lbC
R
L
F
Unstable Negative Data
US,+0005.593
[
kgC
R
L
F
Unstable Positive Data
OL,+9999.999
[
kgC
R
L
F
‘E’ display
OL, -9999.999
[
lbC
R
L
F
‘-E’ display
“
[
