7-3. How to Use
1 Attach the water jacket on the table along the guides.
Make sure that the water jacket is slid furthest along
the guides until stopped.
2 When the water jacket is used, be sure to raise or
remove the protector.
3 Use much care so that the sensor plates and the
temperature sensor do not come into contact with the
inner wall of the sample. If they are in contact, a
measurement error may occur.
4 Be sure to adjust the sample surface to the center of the narrow part of the sensor plates.
SV-1A SV-10A/SV-100A
Slide furthest
until sto
