SV-1A/SV-1H output format example
Viscosity
/
Temper-
ature
Display Output format example Remarks
LLLLL mPa･s
+00000.00,mPa s,+025.67,C
Zeroes are output for below measuring
range error.
0.30 mPa･s
+00000.30,mPa s,+025.67,C
10.0 mPa･s
+00010.00,mPa s,+025.67,C
100 mPa･s
+00100.00,mPa s,+025.67,C
1.00 Pa･s
+01000.00,mPa s,+025.67,C
For 1000 mPa⋅s or greater, the displayed unit
is Pa⋅s, but the output unit remains mPa⋅s.
mmPa･s
/
°C
H Pa･s
+01200.00,mPa
s,+025.67,C
1200 is output for above measuring
range error.
L Pa･s
+000.0000, Pa s,+051.23,F
Zeroes are output for below measuring
range error.
0.0003 Pa･s
+000.0003, Pa s,+051.23,F
0.0100 Pa･s
+000.0100, Pa s,+051.23,F
0.100 Pa･s
+000.1000,
Pa s,+051.23,F
1.00 Pa･s
+001.0000, Pa s,+051.23,F
Pa･s
/
°F
H Pa･s
+001.2000,
Pa ,+051.23,F
1.2 is output for above measuring range error.
L cP
+000.0000, cP ,+025.67,C
Zeroes are output for below measuring
range error.
0.30 cP
+00000.30, cP ,+025.67,C
10.0 cP
+00010.00, cP ,+025.67,C
100 cP
+00100.00, cP ,+025.67,C
10.0 P
+01000.00, cP ,+025.67,C
For 1000 cP or greater, the displayed
unit is P, but the output unit remains cP.
CcP
/
°C
H P
+01200.00,
cP ,+025.67,C
1200 is output for above measuring
range error.
L P
+000.0000, P ,+051.23,F
Zeroes are output for below measuring
range error.
0.0030 P
+000.0030, P ,+051.23,F
0.100 P
+000.1000, P ,+051.23,F
1.00 P
+001.0000,
P ,+051.23,F
10.0 P
+010.0000,
P ,+051.23,F
P
/
°F
H P
+012.0000,
P ,+051.23,F
12 is output for above measuring range error.
: Space (ASC 20h)
