94
AX-SV-54 Cup Set (10 mL / 13 mL / 45 mL)
(Use the AX-SV-51 Stand Set if necessary.)
• Used when a small amount of sample will be
measured.
- Consists of :
Sample cup (45 mL) 5 pcs
Small sample cup (10 mL) 5 pcs
Small sample cup cover 5 pcs
(All: Polycarbonate, Operating temperature: 120°C max.)
Used when organic solvents will be measured.
Glass sample cup (Capacity: Approx.13 mL) 2 pcs
(Pyrex® glass, Operating temperature: 230°C max.)
Glass sample cup holder (Stainless steel) 1 pc
• Water Jacket
Used, in combination with a commercially available
constant temperature bath for heating medium
circulation, to maintain the sample temperature
constant or to measure the viscosity while changing
the sample temperature.
- Consists of :
Water jacket 1 pc
(Main body: Polycarbonate, Packing: Silicone rubber,
Washer: Nylon)
Glass sample cup
Small sample cup
Water jacket
Circulation nozzle
Small sample cup cover
Screw
