27MHGRVX-B2 Module Technical Guide

APPENDIX B: COMPATIBILITY

MHGRVX Series Drop-In Replacement

Table 9: MHGRVX Series Modules Compatibility

C Communication Valve Dependant Compatibility Other

MHGRV-X Yes No MHGRV II, MHGRVX-A1*, MHGRVX-B1*

MHGRVX-A1 No No MHGRV-X*, MHGRVX-B1*

MHGRVX-A2 No Sanhua EBV05H only MHGRVX-B2

MHGRVX-B1 No No MHGRV-X*, MHGRVX-A1* Additional AOUT input on board

MHGRVX-B2 No Sanhua EBV05H only MHGRVX-A2 Additional AOUT input on board

*These modules do no support I

C communication.
