LCD DISPLAY SCREENS
11
BACnet
®
General Controller Technical Guide
BGC Main Screens
BGC Main Screens
Refer to the following map when navigating through the LCD Main
Screens.Therstscreenisaninitializationscreen.Toscrollthrough
the rest of the screens, press the <DOWN ARROW> button.
BGC UNIT
Ver X.XX
RELAYS
BINARY
INPUTS
ANALOG
OUTPUTS
Press to go to the ANALOG OUTPUT Screen.
Press to scroll through RELAY Screens.
Press to go to the RELAYS Screen.
ANALOG
INPUTS
Press to scroll through ANALOG INPUT Screens.
Press to go to SETTINGS Screen.
SETTINGS
Press to scroll through SETTINGS Screens.
Press to go to the BINARY INPUTS Screen.
Press to scroll through the ANALOG OUTPUT Screens.
Press to go to the ANALOG INPUTS Screen.
Press to scroll through the BINARY INPUT Screens.
