Full Digital Module
Technical Guide
8
Start Up and Commissioning
General
In order to have a trouble free start-up, it is important to follow a few
simple procedures. Before applying power for the fi rst time, it is very
important to run through a few simple checks.
One of the most important checks to make before powering up the system
for the fi rst time is to make sure that the VCM-X Modular or VCM-X
Modular E-BUS Controller is confi gured properly for your application.
Refer to the VCM-X Controller Technical Guide or VCM-X Modular
E-BUS Controller Technical Guide for more information. A handheld
Modular Service Tool, Modular System Manager, or System Manager
Touch Screen connected to the VCM-X Modular or VCM-X Modular
E-BUS Controller will allow you to confi gure your application. Refer to
the VCM-X / RNE Operator’s Interfaces SD Technical Guide or System
Manager TS II Technical Guide for more information.
Check all wiring leads at the terminal block for tightness. Be sure that
wire strands do not stick out and touch adjacent terminals. Confi rm
that all sensors required for your system are mounted in the appropriate
location and wired into the correct terminals.
WARNING: Observe polarity! All boards must be wired
GND-to-GND and 24 VAC-to-VAC. Failure to
observe polarity could result in damage to the
boards.
Table 1: Unit Confi gurations Chart
UNIT CONFIGURATIONS
PERMUTATION
SYSTEM A SYSTEM B
HARDWARE
VCM-X WSHP
CONFIGURATION
Comp A1 Comp A2 Comp B1 Comp B2
Relay 1 Relay 2 Relay 3 Relay 4
1 On/Off On/Off
Use VCM-X Modular
Series Controller Only
2 Compressors
2 Digital On/Off
Use VCM-X Modular
Series Controller Only
2 Compressors
Digital Compressor
3 Digital Digital
Use VCM-X Modular
Series Controller and
Full Digital Module
2 Compressors
Full Digital
4 On/Off On/Off On/Off On/Off
Use VCM-X Modular
Series Controller Only
4 Compressors
5 Digital On/Off On/Off On/Off Not Available Not Available
6 Digital On/Off Digital On/Off
Use VCM-X Modular
Series Controller Only
4 Compressors
Digital Compressor
7 Digital Digital Digital Digital
Use VCM-X Modular
Series Controller and
Full Digital Module
4 Compressors
Full Digital
In the Cooling Mode, the Compressors will stage in the following order:
Permutations 1, 2 & 3: Compressor A1 -> Compressor A2
Permutations 4: Compressor A1 -> Compressor A2 -> Compressor B1 -> Compressor B2
Permutations 6: Compressor A1 & Compressor A2 -> Compressor B1 -> Compressor B2
Permutations 7: Compressor A1 & Compressor A2 -> Compressor B1 & Compressor B2
In the Dehumidifi cation Mode, the Compressors will stage in the following order:
Permutation 4: Compressor A1 & Compressor A2 -> Compressor B1 -> Compressor B2
All other permutations in the Dehumidifi cation Mode stage as described in the Cooling Mode.
