VCC-X STATUS
VCC-X Operator Interface SD
56
VCC-X Status Screens
Status Screens - General Procedures
From any menu screen, press <STATUS>. The Unit Selection Screen,
shown below,
will appear requesting that you enter the unit ID number.
Enter Unit Address
Then Press Enter
Selected Unit#: XXXX
No Communication
Enter the correct unit ID number of the Controller you want to view
and
press <ENTER>. Once communication is established, “No Com-
munication” will be replaced with “Press Down.” Then press <>.
You will then see the Status Selection Screen(s) below:
VCC-X Status
RSM-VFD & HP Status
RSM DIGITAL Status
Select & Press Enter
Select VCC-X Status. Then press <ENTER>.
The fi rst VCC-X Status Screen will appear. Press <> to scroll
through the screens.
NOTE: If “No Communication” remains, it indicates a
communication failure to the controller.
Status Screen #1 - Date and Time
VCC-X v1.02 ID #
Controller Date/Time
01/16/2015 05:00 PM
Line 2 Controller Date/Time
Line 3 MM/DD/YYYY HH:MM XX
(Month, Day, Year) (Hour, Minutes, AM or PM)
Status Screen #2 - Application Type, Schedule
Mode & HVAC Mode
VCC-X v1.02 ID #
App Type
Schedule Mode
HVAC Mode
Line 2 App Type:
Constant Volume Single Zone VAV
VAV VAV w/Tempering
Make Up Air Space w/High OA%
Line 3 Schedule Mode:
Unoccupied Holiday Occupied
Occupied Forced Occupied
Override Forced Unoccupied
Holiday Unoccupied Remote Occupied
Line 4 HVAC Mode:
Off Dehum Vent
Vent Mode Dehum Cool
Cool Mode Dehum Heat
Heat Mode Warm Up
Defrost Cool Down
Remote Cool Remote Heat
Remote Vent RH Remote Cool RH
Remote Heat RH
Status Screen #3 - Controlling Temperature,
Cooling & Heating Setpoints
VCC-X v1.02 ID #
Ctrl Temp: 0.0ºF
Cool Spt: 0.0ºF
Heat Spt: 0.0ºF
Line 2 Controlling Temperature
This is the temperature of the sensor that is confi gured as
the HVAC Source (Mode Enable) Sensor. This can be
the Supply Air, Return Air, Outdoor Air, or Space
Temperature Sensor.
Line 3 Cooling Setpoint
Based on the current Occupied/Unoccupied Mode
of operation. (Refl ects any active resets.)
Line 4 Heating Setpoint
Based on the current Occupied/Unoccupied Mode
of operation. (Refl ects any active resets.)
