VCC-X Operator Interface SD
RSM STATUS
69
RSM Status Screen #3 - Coil (Suction Line)
Temperature 1, Superheat 1, and Expansion
Valve 1 Position
RSM #1-4 Status
Coil Tmp 1: 0.0ºF
Superheat 1: 0.0ºF
EXV 1 Pos: 0.0%
Line 2 Coil (Suction Line) Temperature 1
Current Coil (Suction Line) Temperature 1.
Line 3 Superheat 1
Current Superheat temperature for Expansion Valve 1.
Line 4 Expansion Valve 1 Position
Modulating position for Expansion Valve 1.
RSM Status Screen #4 - Coil (Suction Line)
Temperature 2, Superheat 2, and Expansion
Valve 2 Position
RSM #1-4 Status
Coil Tmp 2: 0.0ºF
Superheat 2: 0.0ºF
EXV 2 Pos: 0.0%
Line 2 Coil (Suction Line) Temperature 2
Current Coil (Suction Line) Temperature 2.
Line 3 Superheat 2
Current Superheat temperature for Expansion Valve 2.
Line 4 Expansion Valve 2 Position
Modulating position for Expansion Valve 2.
RSM Status Screen #5 - Head Pressure
Setpoint and Condenser Fan Signal
RSM #1-4 Status
Head Pr: 0psi
Setpoint: 0psi
Cond. Signal: 0.0%
Line 2 Head Pressure 1
If a Head Pressure Transducer is connected, this line
indicates the current Head Pressure reading.
Line 3 Head Pressure Setpoint
The current Head Pressure Setpoint.
Line 4 Condenser Signal
The current percentage signal being sent to
the Condenser Fan or Valve in order to maintain the
Head Pressure Setpoint.
RSM HP Status Screen #6 - Coil (Suction Line)
Temperature 3, Superheat 3, and Expansion
Valve 3 Position
RSM HP #1-4 Status
Coil Tmp 3: 0.0ºF
Superheat 3: 0.0ºF
EXV 3 Pos: 0.0%
Line 2 Coil (Suction Line) Temperature 3
Current Coil (Suction Line) Temperature 3.
Line 3 Superheat 3
Current Superheat temperature for Expansion Valve 3.
Line 4 Expansion Valve 3 Position
Modulating position for Expansion Valve 3.
RSM HP Status Screen #7 - Coil (Suction Line)
Temperature 4, Superheat 4, and Expansion
Valve 4 Position
RSM HP #1-4 Status
Coil Tmp 4: 0.0ºF
Superheat 4: 0.0ºF
EXV 4 Pos: 0.0%
Line 2 Coil (Suction Line) Temperature 4
Current Coil (Suction Line) Temperature 4.
Line 3 Superheat 4
Current Superheat temperature for Expansion Valve 4.
Line 4 Expansion Valve 4 Position
Modulating position for Expansion Valve 4.
RSM HP Status Screen #8 - Leaving Water
Temperature and Proof of Flow
RSM HP #1-4 Status
Leaving H2O: 0.0ºF
H2O Flow: NO
Line 2 Leaving Water Temperature
Current Leaving Water Temperature.
Line 3 Water Flow
Current Status of Proof of Water Flow.
RSM Status Screen #9 - Alarms
RSM #1-4 Alarms
Active Alarms: No
See Active Alarms
on the RSM LCD
RSM-VFD & HP Status Screens
To Next Page
