VCC-X Operator Interface SD
RSM STATUS
71
RSM-DIGITAL Status Screens
RSMD Status Screen #3 - Coil (Saturation)
Temp & Setpoint & Suction Pressure
RSMD #1-4 Status
Coil Temp: 0.0ºF
Coil Setpt: 0.0ºF
Suction Pr: XXX PSI
Line 2 Coil (Saturation) Temperature
If a Suction Pressure Transducer has been installed and
confi gured on the unit, the calculated Evaporator Coil
Suction (Saturation) Temperature will appear on this
line. If not, this line will display 0°F.
Line 3 Coil (Saturation) Temperature Setpoint
During DX dehumidifi cation, compressor(s) will be
staged/modulated to maintain this Coil Suction
(Saturation) Temperature Setpoint. If indoor humidity
reset of the Coil Setpoint has been confi gured, this will
be the current calculated setpoint.
Line 4 Suction Pressure
This is the current Suction Pressure.
RSMD Status Screen #4 - Head Pressure
Setpoint and Condenser Fan Signal
RSMD #1-4 Status
Head Pr: 0psi
Setpoint: 0psi
Cond Signal: 0.0%
Line 2 Head Pressure 1
If a Head Pressure Transducer is connected, this line
indicates the current Head Pressure reading.
Line 3 Head Pressure Setpoint
The current Head Pressure Setpoint.
Line 4 Condenser Signal
The current percentage signal being sent to
the Condenser Fan or Valve in order to maintain the
Head Pressure Setpoint.
RSMD Status Screen #5 - Alarms
RSM #1-4 Alarms
Active Alarms: No
See Active Alarms
on the RSM LCD
Line 2 Active Alarms
This screen will display Yes if there are active alarms.
Active alarms can be viewed on the LCD display of the
RSMD Module.
