AAON V3-E - V3 Series Feature String Nomenclature; Cooling and Heating Feature Options

V3 Series Feature String Nomenclature
Model Options
:
Unit Feature Options
GEN
SIZE
ORENT
MJREV
VLT
CORR
A1
A2
A3
A4
B1
B2
B3
1A
1B
1C
1D
2
3
4
5A
5B
5C
6A
6B
6C
7
8
9
10
11
12
13
14A
14B
V3
-
B
R
B
-
2
-
0
-
2
6
H
A
-
E
E
A
:
A
B
C
H
-
0
E
A
-
F
F
B
-
0
C
0
-
A
0
0
0
0
0
0
0
0
0
0
0
0
0
B
0
0
0
15
16
17
18
19
20
21
22
23
11
V3 Base Model Description
BASE MODEL
SERIES AND GENERATION
V3 = Horizontal - Back Intake, Front Discharge
UNIT SIZE
A = Up to 1,200 cfm
B = Up to 2,000 cfm
C = Up to 4,000 cfm
D = Up to 6,000 cfm
E = Up to 10,000 cfm
UNIT ORIENTATION
R = Right Hand Connections
L = Left Hand Connections
REVISION
B = Second Revision
VOLTAGE
1 = 230V/1Φ/60Hz
2 = 230V/3Φ/60Hz
3 = 460V/3Φ/60Hz
4 = 575V/3Φ/60Hz
8 = 208V/3Φ/60Hz
9 = 208V/1Φ/60Hz
CORROSION PROTECTION
0 = None
A = Interior Corrosion Protection
Model Option A: COOLING
A1: COOLING TYPE
0 = No Cooling
1 = R-410A DX Cooling
2 = Chilled Water Cooling
A2: COOILNG ROWS
0 = No Cooling
4 = 4 Row Coil
6 = 6 Row Coil
8 = 8 Row Coil
A3: COOLING STAGES
0 = No Cooling
1 = Single Circuit
2 = Two Circuits - Interlaced Coil
D = Double Serpentine
F = Single Serpentine
H = Half Serpentine
Q = Quarter Serpentine
A4: COOLING FPI
0 = No Cooling
A = 10 fpi
B = 8 fpi
C = 12 fpi
D = 14 fpi
