Focus Adjusment / Throw Distance
5
• Spin the focus wheel up or down until the image becomes
clear.
Focus Adjustment
DIAGONA
L
SCREEN SIZE
16:9 Aspect Ratio
Throw Distance
Units: Inches
20
30
40
50
60
70
80
90
100
Diagonal Size
Units: Inches
32
48
64
80
96
112
128
144
160
Throw Distance Chart
Throw Ratio 0.7:1
*minimum throw distance: 10 inches
