- 33 -
. . . ADDENDUM FOR "SURGE PROTECTION" OPTION OF THE TRANSMITTERS
Fig. 1 - SURGE PROTECTOR
Stuck on label to disclose the
presence of the surge protector
Two holes for
M4x18 mm
fixing screws
+/- Terminals
Socket for
built-in indicator
TERMINAL BLOCK
(Side Sect. View)
Terminals to be welded
into the specified holes
TERMINAL BLOCK
(Front view)
SURGE PROTECTOR
(P.C. Board)
TERMINAL BLOCK
(Back view)
Self-tapping screw M2.9x6 mm to secure
the surge prot. p.c. board
Terminal holes to
be used for welding
the +/- eyelet
terminals of the
"RF" Filter wires.
Two notches on the ext
plastic case wall
to lodge the surge prot.
p.c. board
Self-tapping screw
M2.9x6mm

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ABB 2600T EN Series and is the answer not in the manual?

ABB 2600T EN Series Specifications

General IconGeneral
Accuracy±0.075% of span
Process Temperature-40 to 85 °C (-40 to 185 °F)
Ambient Temperature-40 to 85 °C (-40 to 185 °F)
Power Supply10.5 to 45 V DC
Housing MaterialAluminum or Stainless Steel
TypePressure Transmitter
Output Signal4-20 mA HART, PROFIBUS PA, FOUNDATION Fieldbus
Protection RatingIP66, IP67
Measurement TypeAbsolute, gauge, differential pressure
Stability±0.1% of URL per year
Electrical ConnectionM20x1.5, 1/2-14 NPT
Process Connection1/2" NPT, 1/4" NPT
CertificationsATEX, IECEx, CSA
Communication ProtocolHART, PROFIBUS PA, FOUNDATION Fieldbus
