- 34 -

. . . ADDENDUM FOR "SURGE PROTECTION" OPTION OF THE TRANSMITTERS

Red

Black

Fig. 2a

Connection for terminal block and housing.

Note: Before to fix the terminal block to the housing put the

two wires in the position as shown above, in order to avoid

any damages.

Fig. 2b

Connection for terminal block and housing, with surge

protection.

Note: Before to fix the terminal block to the housing put the

two wires in the position as shown above, in order to avoid

any damages.

Black

Red

Green
